Description
Details
Applicable Door Depth: Fits doors 35mm to 55mm thick
Applicable Door Spacing: The lock requires a clearance at min. 3-3/4″ from the edge of the door for 2-3/8″ (60mm) backset and 4-1/4″ clearance for 2-3/4″ (70mm) backset.
Lock Type: Deadbolt
- 1 Master Code
- Program up to 70 User Codes and RF Tags combined.
- 4-12 Digit User Code
- Automatic Locking Capabilities. Battery operated with emergency power contact.
- Randomly generated code feature prevents any fingerprint marks left on the screen
- Random Security Code
- Double Authorization Mode Capability: Access of entry granted after both PIN code and RF card have been authenticated
- Low battery indicator function. Sounds of low battery and indicator on the touchpad screen
- Emergency Power Supply. Use a 9V battery from the outside to power the lock temporarily in case the batteries run out
- Battery operated: DC 6V AA Alkaline Battery (4) included. Based on regular use of 10 times a day, batteries will last approximately 6 months.
- Requires minimum of 3-3/4 inches on the face of the door from the edge for the lock to sit flush
Design
Samsung door locks have a sleek modern design that complements any interior or exterior door for residential homes, apartments, or commercial business offices.
Easy to Use
Use the digital touchscreen numeric keypad to enter a password, RFID key or the mechanical key to enter. Close the door and the magnetic sensor automatically locks the door for you.
Easy Installation
Installs on standard 160/161 cylinder prep doors. No additional drilling, universal deadbolt to adjust between 60mm and 70mm, can be installed on left or right side. Minimum of 3-3/4 inches on the face of the door is required for the lock to sit flush.
Security
- Rigorously tested construction, random security code feature, intrusion alarm, fire detection sensor, anti tampering lock out.
- Double authorization mode capability: Access of entry granted after both PIN code and RF card have been authenticated
Specification
| PIN Code | 4~12 digit combination | ||
| Capacity Combined | PIN Code | Up to 70 | |
| RF Key | Up to 70 | ||
| Lockset | Tubular Lock/Deadbolt | ||
| Applicable Door Depth | 35~55mm (1.4~2.2 inches) | ||
| Material | Zn, Al, Polycarbonate | ||
| Humidity | 20~80% | ||
| Temperature | -20°C ~ +60°C | ||
| Power | DC 6V AA Alkaline Battery (4) | ||
| Battery Life | Approx. 6 Months (Ten Times Per Day) | ||
| Product Size (length×width×height) | Exterior Body | 36.5×68×180 (mm) 1.4×2.7×7.1 (inches) | |
| Interior Body | 38.3×68×180 (mm) 1.5×2.7×7.1 (inches) | ||
Included in the Box
- Interior and Exterior Unit
- Interior Rubber Pad
- Interior Mounting Plate
- Adjustable Deadbolt (60 and 70mm backset)
- Strike Parts (Strike and Dust Box)
- Magnetic Sensor (Door Side and Door Frame Side)
- Tail Piece
- Screws
- RF Key tags (4)
- AA Batteries (4)
- User Manual
